Fancier SynthPatches

To support noteUpdates, you merely supply a noteUpdateSelf: method. It is up to you what parameters you want to allow to change in a noteUpdate. Example:

+ noteUpdateSelf: aNote
{
	[OSC setFreq: [aNote freq]];
 	[OSC setAmp: [aNote parAsDouble: MK_amp]];
  	[OUT setBearing: [aNote parAsDouble: MK_bearing]];
 	 return self;
}


To relax the restriction that all MKNotes need to have every parameter present, you can set the parameter in noteOnSelf: and noteUpdateSelf: only when it is present, store its value in an instance variable, and set it back to a default value in noteEnd. E.g., if there is an instance variable freq.

+ noteOnSelf: aNote
{
	if ([aNote isParPresent: MK_freq])
	    freq = [aNote freq];
 	[OSC setFreq: freq];
 	. . .
}

+ noteEndSelf
{
 	freq = 440;
 	[OSC setAmp: 0.0];
 	return self;
}


To add an amplitude envelope, we need to use an AsympUG MKUnitGenerator to create the envelope, write it to a patch point and use an oscillator that is capable of reading its amplitude from a patchpoint. The OscgafiUG supports reading both its amplitude and its frequency from a patchpoint. The C function MKUpdateAsymp() makes it easy to apply an envelope with AsympUG and supports attack and release times, scaling values, and phrase transitions:

MKUpdateAsymp(
	AsympUG *anAsymp,	// asymp instance
	MKEnvelope *ampEnv,	// the envelope
	double amp0,	// value when env at 0
	double amp1,	// value when env at 1
	double ampAtt,	// attack time
	double ampRel,	// release time
	double portamento, 	// transition time on rearticulation
	MKPhraseStatus phraseStatus);  	// see below


Any argument may be omitted. For double arguments, omitting the argument means supplying the special value MK_NODVAL (which stands for “No Double Value”).

Phrase status is obtained by sending [self phraseStatus];
